Disenyo ng Overhead Transmission Line
We provide overhead transmission line design services, offering tailored, efficient, and reliable solutions for high-voltage power transmission systems.
- Service Type: Overhead Transmission Line Design
- Scope: Routing, tower placement, load analysis, and structural optimization
- Compliance Standards: ISO 9001:2015, IEC, GB/T2694-2010
- Tools Used: CAD software, load simulation tools, GIS mapping systems
- Applications: National power grids, renewable energy systems, industrial power networks
Overview
Ang Overhead Transmission Line Design ay nagsasangkot ng pagpaplano at engineering ng mga linya na may mataas na boltahe na nasuspinde sa mga tower o poste upang matiyak ang mahusay na paghahatid ng kuryente sa malawak na distansya. Ang mga disenyo na ito ay kritikal para sa pagpapanatili ng pagiging maaasahan ng sistema ng kuryente, pagbabawas ng pagkawala ng enerhiya, at pagtiyak ng ligtas na operasyon.
Ang aming mga serbisyo ay nagbibigay ng na-customize na mga disenyo ng linya ng transmisyon ng overhead na nababagay sa mga tukoy na kinakailangan ng proyekto. Gamit ang mga advanced na tool sa engineering, premium na materyales, at pagsunod sa mga internasyonal na pamantayan sa kaligtasan, naghahatid kami ng nasusukat, mahusay, at matibay na mga sistema na sumusuporta sa modernong imprastraktura ng enerhiya.
- Customized Designs: Tailored solutions to meet specific routing, load, and environmental requirements.
- Advanced Engineering Tools: Use of CAD software, load simulation, and GIS mapping for precise and optimized designs.
- Material Recommendations: High-grade materials such as galvanized steel for towers and aluminum or copper for conductors.
- Energy Efficiency: Designs focused on minimizing energy losses during transmission to maximize efficiency.
- Environmental Resilience: Structures engineered to withstand extreme weather conditions, seismic activity, and diverse terrains.
- Global Standards Compliance: Alignment with ISO, IEC, and other international safety and performance benchmarks.
- Future-Ready Solutions: Scalable designs to accommodate network expansions and integration of emerging technologies.
- National Power Grids: Designing high-voltage lines to support regional and national energy distribution.
- Renewable Energy Integration: Connecting solar, wind, and hydropower installations to the grid.
- Industrial Power Systems: Tailored overhead line designs for energy-intensive industrial facilities.
- Substation Connections: Designing lines that efficiently link power plants and substations.
Our overhead transmission line design process is guided by rigorous quality control measures at every stage. Each design undergoes comprehensive testing, compliance checks, and detailed inspections to ensure alignment with international safety standards. These processes guarantee efficient energy flow, long-term reliability, and seamless integration into existing power networks.
Feature
- Durable and long-lasting: The angular transmission tower model XY-35 is manufactured to withstand any adverse weather conditions and has a service life of more than 30 years under different installation conditions.
- High voltage capability: The product applies to 33kv and 35kv voltage levels, which indicates that its key application is in power transmission.
- Customizable and durable coating: For exhibition of corrosion resistance and long durability the tower body uses hot-dip galvanizing surface treatment.
- Wide range of heights: The product height range for installation is 3-120m to suit various installations.
- Compliance with international standards: All our products are certified with ISO 9001:2015, which is an internationally recognized quality standard as well as user standards
Specification
| Tension: 10kV-500kV | Origin: Sichuan Province, China |
| Brand: Xiangyue | Model: XY-ET |
| Product Name: Transmission Line Tower Angle Lattice Power Steel Tower | Single Piece Gross Weight: 200000.000kg |
| Surface Treatment: Hot-dip Galvanizing | Rated Voltage: 10kV-500kV |
| Certification: ISO9001:2015 | Wind Speed: 120km/h |
| Service Life: More than 30 Yes | Color: Personalized |
| Sales Unit: Single Item | Single Piece Packaging Size: 1150X192X150cm |
